Narrow angle CCD bracket camera
Narrow angle CCD bracket camera

Narrow angle CCD bracket camera

£68.00
(Inc. 20% VAT)
(£56.67 Exc. VAT)
In stock
+
Weight
300 g
Introduction to product

There are some situations when a wide angle reversing camera is unsuitable. You may want to use a system as an always on rear view and wide angled cameras can make judging distance more difficult. This camera has a viewing angle of 60 degrees and gives a much more realistic perception of distance. It uses the same CCD sensor as our other CCD bracket reversing cameras and the night vision is just as good. It is a PAL camera.

Specification of camera
  • 1/3 700TVL SONY CCD
  • Video System:- PAL
  • Pixels:- PAL:752(H)*582(V)
  • Horizontal Resolution:-700 TVL
  • Min Illumination:- 0.001Lux (0 Lux IR on)
  • SNR:- ≥50dB
  • Electronic Shutter:- 1-1/10000(S)
  • Video Output:- 1.0V±0.5Vp-p 75Ω
  • View Angle:- 120°  (Unless stated otherwise in information tab)
  • Working Voltage:- DC9V-12V±0.5V
  • Consumption:- 70mA±10%
  • Waterproof Rate:- IP68
Model
CAM063
Bar Code
5060342250667
Vehicle
Motorhome
Voltage
12 volt
Connector type
4 pin aviation
TVL
700 TVL
Special features
18 IR LEDs for night vision
Type of sensor
CCD
Sensor manufacturer
Sony
Sensor size
1/3" sensor
Camera angle
60 degrees
